BR Standard Riddles "Std 9F" Class 2-10-0
General
| Designer |
Robert "Robin" Riddles |
| Introduced |
1954 |
| Description (1957) |
British Railways' standard 2-10-0 freight locomotives, with 5'0" driving wheels and 2 outside cylinders 20" x 28". They were built from 1954 onwards and construction is still proceeding in 1958. Nos. 92020-92029 are fitted with Franco-Crosti boilers. The only steam locomotives now being built. |
| BR Standard |
Y |
| Wheel Arrangement |
2-10-0 |
| Number Built as Std 9F |
251 |
| First in Service |
31/01/1954 |
| Last in Service |
06/1968 |
| Manufacturers |
|
| Orders |
|
|
|
|
Wheels
|
Standard |
Crosti |
ex Crosti |
| Pony |
3' |
As Standard |
As Standard |
| Drivers |
5' |
As Standard |
As Standard |
| Locomotive Wheelbase |
30' 2" |
As Standard |
As Standard |
| Tender Wheelbase |
14' |
As Standard |
As Standard |
| Total Wheelbase |
55' 11" |
As Standard |
As Standard |
| Descriptive Wheelbase |
8' 6" + 5' 5" + 5' 5" + 5' 5" + 5' 5" + 11' 9" + 7' 0" + 7' 0"
= 55' 11" |
As Standard |
As Standard |
Dimensions
|
Standard |
Crosti |
ex Crosti |
| Length (over buffers) |
61' 2" |
As Standard |
As Standard |
| Weight (loco only) |
86t 14cwt |
90t 4cwt |
83t 12cwt |
|
